LONG BLADE STRAIGHT BIT 1/2'X1-1/2'
Features
- ½″ diameter straight profile for true, square-walled grooves.
- 1-½″ cutting length provides extra reach for deeper operations.
- Precision-ground cutting edges for smooth finish and reduced tear-out.
- Rigid body to minimise deflection and chatter on long plunges.
- Router-collet compatible (use the correctly matched shank/collet size).
Benefits
- Deep capacity: handles thicker panels, laminated stacks and long mortises.
- Clean bottoms: flat-floor grooves reduce sanding and fit-up time.
- Accurate tracking: works well with fences, guides and templates.
Extra Information
- For deep cuts, step down in stages (3–5 mm per pass) to control heat and load.
- Match RPM and feed rate to material; avoid dwelling to prevent burning.
- Ensure the bit is fully seated in the collet (at least 80% shank engagement) and tightened securely.
- Clear chips between passes — especially important with long cutting edges.
Pro Tip
- When routing deep mortises, plunge in stair-steps along the length, then take a final full-width pass to flatten the floor.
- On veneered panels, make a shallow scoring pass first to protect the veneer edge, then complete the depth in increments.
| Description | Specification |
| Packaging Type | Hanging card / Blister |
| Material | Cutting Edge: Tungsten Carbide Body & Shank: HSS (High Speed Steel) |
| Package Dimensions | 138(L) x 78(W) x 46(H)mm |
| Package Weight | 104.49g |
| Tool Dimensions | 58.49(L) x Ø25.4mm |
| Tool Weight | 83.1g |
| Cutting Diameter | 1" |
| Cutting Depth | 1" |
| Shank Diameter | 1/2" |
| Shank Length | 32mm |
| Country of Origin | Republic of China (PRC) |
| Warranty | 6 Months |
| Content | 1x Straight Router Bit |
Bulk
| Inner Box | |
| Dimensions (box/pack) | 385(L) x 168(W) x 73(H)mm |
| Weight (box/pack) | 1.36kg |
| Qty (box/pack) | 10 |
| Outer Box | |
| Dimensions (box/pack) | 405(L) x 370(W) x 310(H)mm |
| Weight (box/pack) | 14.33kg |
| Qty (box/pack) | 100 |
Safety
- Wear eye, hearing, and dust protection.
- Secure the workpiece and feed against bit rotation to prevent kickback.
- Let the router reach full speed before engaging; stop fully before lifting out.
- Inspect bit and collet regularly; replace if dull, chipped, or cracked.
