Radius Gauge 15.5 - 25mm CONVEX/CONCAVE with 30 leaves/blades
SERIES 941
SERIES 941
The ACCUD AC941-025-30 Radius Gauge (1-7mm Convex/Concave) is a precision measurement tool used to accurately gauge both convex and concave radii within the range of 1mm to 7mm. It is ideal for tasks such as checking the radius of edges, grooves, or surfaces, particularly in machining, metalworking, and quality control applications.
It is a high-quality, durable tool designed to provide accurate convex and concave radius measurements. Its compact design, a wide range of measurement sizes, and precision make it an indispensable tool in machining, metalworking, and quality control.
- Check the radius
- With concave and convex surface in each size
Applications:
- Machining and Fabrication: Used to check the radius of machined parts and ensure they conform to design specifications.
- Metalworking: Useful for gauging the radius of edges and grooves on metal surfaces, ensuring precision during manufacturing.
- Quality Control: Commonly used in quality inspection processes to verify that the radii of components meet the required specifications.
- Tool and Die Making: Helps in designing and inspecting tools and dies that require specific radii for shaping and cutting materials.
Features
Dual Functionality:
- Convex & Concave Measurement: The gauge is designed to measure both convex (external) and concave (internal) radii, offering flexibility for various types of measurements on different surfaces.
Radius Range:
- 1mm to 7mm: This gauge covers a broad range of radii, from 1mm to 7mm, making it versatile for many applications requiring precision measurements within this range.
High Precision:
- Accurate Measurement: Each blade or gauge leaf is finely machined to match specific radius sizes, ensuring precise measurements, critical in quality assurance and component design.
Durable Construction:
- Steel Blades: The blades are made from hardened steel, ensuring durability and resistance to wear, making it suitable for use in demanding industrial environments.
Compact Design:
- Foldable Blades: The blades are often arranged in a fan-like configuration that can be folded into a compact design for easy storage and portability. Individual blades can be selected and unfolded for quick and efficient measurement.
Clear Markings:
- Laser-Etched Labels: Each blade is clearly marked with its corresponding radius size (in millimeters), allowing users to quickly identify the correct blade for the measurement task.
Technical Specifications
